BEECHCRAFT gauges

Custom gauges for BEECHCRAFT cockpit builders.

Can be driven by servos or steppers.

Available per special request.

Please contact us for design options and pricing.



Software compatibility:

- Mobiflight

- Prosim737 (through Mobiflight)

- SimVim

A320 Brake Pressure

External dimensions:

58x58(front)x52mm

Screw (M4) spacing:

71.5-75.5mm

B737 Stepper motor Flaps gauge

External dimensions:

55x55x55mm

Visible opening required:

38-50mm

Screw (M4) spacing:

58-68mm

Stepper type:

bipolar (VID29)

Driver (included):

EasyDriver

Required controller:

Arduino MEGA 2560 R3 compatible board



Microcontroller:ATmega2560
OperatingVoltage:5V (USB powered)
Digital I/O Pins:54 (15 PWM)
Analog Input Pins:16
DC Current per I/O Pin:20 mA
DC Current for 3.3V Pin:50 mA
Clock Speed:16 MHz

B737 Wet Compass

Requirements to control 28BYJ-48 stepper motor based compass under MobiFlight:



Hardware:

- ULN2003 driver (included)

- Arduino MEGA 2560 R3 or compatible board



Software:

- FSX / P3D

- FSUIPC

- Arduino-IDE (free)

- MobiFlight Connector (free)



Setup:

- Compass Configuration under MobiFlight



External dimensions: 89(W)x101(H)x103(D)mm

Material: Acrylic/PLA

Motor: 28BYJ-48 stepper

Driver: ULN2003 (included)

Backlight: 5V LED

Controller: Arduino MEGA 2560 R3 commpatible board

Keyestudio MEGA 2560 R3

Vertical Card Compass

External dimensions: 60(W)x86(H)x51(D)mm

Material: Acrylic/PLA

Motor: 28BYJ-48 stepper

Driver: ULN2003 (included)

Backlight: 5V LED

Controller: Arduino MEGA 2560 R3 commpatible board

External dimensions:

42x42(front)x54mm

(back servo plate: 48.5x42mm)

Visible opening required:

34-38mm

Screw (M4) spacing:

43-47mm

B777 Brake Accum
